Malachite SDR Radio DSP Receiver | 50KHz-2GHz | 3.5 Touch Screen | AM/SSB/NFM/WFM
$195.00
$239.98
-19% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Please kindly note before purchase:1. The software version of this product is 1.10a ??
2. We only sell the hardware, this product does not include follow-up software upgrade service (cannot upgrade to 1.10b).
Description:
Features:
1) The radio is constructed based on SDR principle, and its functions are determined by loaded software.2) The frequency range is 50KHz-200MHz /400MHz-2GHz3) All types of analog modulation: AM, SSB, NFM, WFM;4) Powerful functions: variable filter width, adaptive noise suppressor, threshold noise suppressor, Noise Blanker, AGC, equalizer.5) Fully functional chip msi001 is used;6) The clock frequency of stm32h743 is 480MHz.7) With touch screen: 3.5" IPS display.8) There is a built-in UHF.9) Control: 2 encoders with buttons and a touch screen10) It is powered by an external TYPE-C (for Huawei mobile phone) interface and can be charged by TYPE-C. The internal battery voltage is 3.7V and the capacity is 2500mAh.11) Current consumption when listening to headphones is 300mA.12) Built-in receiving module improves the HF reception on antenna, an additional board with a source follower has been developed. The board will be built into the standard receiver design.13) Connecting to a computer via USB, it can transmit CAT, IQ and audio.14) 160kHz span, with scalability.15) Sensitivity is 0.3??V = 10dB at s/w under the condition of up to 250MHz.16) Due to the characteristics of the msi001 chip used, dynamic blocking range is about 85dB.17) There is backlight control.18) SMA female antenna socket;19) Dimensions 102X74X29mm (excluding the sizes of protrusions).20) Weight 240g.
Package included:
1 x SDR Receiver
1 x Antenna
Package Upgrade(2021/4/29)
Details pictures:
