SVBONY SV305 2MP Astronomy Camera | 1.25 USB Telescope Eyepiece for Planetary Photography
$243.00
$299.18
-19% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Features:About the chipBack-illuminated structure with 2.9um-square unit pixelHigh sensitivity characteristics (two or more times that of the existing product)Improved sensitivity in the near infrared light region (three or more times that of the existing product)Support WDR (multiple exposure WDR, DOL-WDR)Versatile interface ??CMOS parallel, low-voltage LVDS serial, MIPI CSI-2??
Back-illuminated (BSI) CMOS SensorThe SV305 uses an extremely sensitive CMOS sensor, the IMX290. This sensor has very high QE, and very low (0.7e-) read noise, which improved sensitivity in the visible-light and near infrared light regions for industrial applications.
128MB DDR BufferThe SV305 has a built-in 128MB DDRII image buffer. The advantage of the image buffer is that the memory will cache the image and transfer it to the computer when the USB interface is not busy or being interrupted, and the frame will not be lost or corrupted. This buffer also allows a slower computer with USB 2.0 socket to capture every frame without loss even if the USB socket is occasionally busy with other peripherals. This buffer also makes it possible to run multiple cameras using one computer without USB transfer problems.
Any Area ROI SupportThe SV305 has ROI function. A smaller region of interest (ROI) is read out from the sensor, leaving the image scale of the object being imaged, unchanged. Allow arbitrary resolutions to be set.
ADC 12bitThe SV305 camera offers 8 bit output or 12 bit.
Specification:
1.Brand: SVBONY2.Model: SV3053.Sensor: 1/2.8" CMOS IMX2904.Pixel Size: 2.9X2.9??m5.Resolution: 2 Mega Pixels 1920X10806.Shutter: Electronic Shutter7.Max FPS: 130fps??320*240??8.ADC: 12 bit
9.ROI support: Any area ROI.10.On camera image buffer: 128M DDR buffer11.Optic window: IR-cut filter12.Interface: USB 2.013.Net weight: 125g14.Material: Aluminum alloy15.Supported OS: Windows16.Power Consumption: 200mA@5V17.Working Temperature: -0??C~45??C18.Storage Temperature: -10??C~60??C19.Working Relative Humidity: 20%~80% 20.Storage Relative Humidity: 20%~95%
Package Includes:
1 X SV305 Astronomy Camera 1 X USB2.0 Cable 1 X 1.25?? Extension tube1 X C-lens adapter1 X User manual1 X CD (Astronomy software & driver & electronic user manual)1 X Cleaning cloth
Details Pictures:
