Product Description
Features:4 1/2 digit desktop multimeter, large screen white backlight LCD.Measurement function: DC/DC Voltage, AC/DC Current, resistance, capacitance, frequency, hFE, diode and continuity test functionThe maximum measurable voltage is 1000V and the resolution is 10uV.The maximum measurable current is 20A, and the positive and negative electrodes can be switched automatically.
Specifications:
| Model | VC8045-II | |
| Function | Range | Basic accuracy |
| DC Voltage | 200mV/2V/20V/200V/1000V | ??(0.05%+3) |
| AC Voltage | 200mV/2V/20V/200V/1000V | ??(0.8%+80) |
| DC Current | 200??A/2mA/20mA/200mA/2A/20A | ??(0.35%+10) |
| AC Current | 20mA/200mA/2A/20A | ??(0.8%+80) |
| Resistance | 200??/2k??/20k??/200k??/2M??/20M?? | ??(0.1%+5) |
| Frequency | 20KHz/200KHz/20MHz | ??(1.0%+20) |
| Capacitance | 10nF/100nF/1uF/10uF/100uF/1mF/2mF | ??(5%+30) |
| Features | ||
| Diode and hFE test | ?? | |
| Triode test | ?? | |
| Continuity buzzer | ?? | |
| True RMS | ?? | |
| Input impedance | 10 ???? | |
| AC frequency response | 3 times/s | |
| Sampling rate | 40~50kHz | |
| Operation way | Manual range | |
| Max. Display | 19999 | |
| General Information | ||
| Product Color | White | |
| Product Size | 260??220??82mm | |
| Product Weight | Approx:1Kg | |
| Power Supply | AC220V; 110V 50Hz/60Hz | |
Package Includes:
1 x Benchtop Digital Multimeter1 x Power Cable(EU Plug)1 x Test Lead 1 x USB Cable 1 x CD1 x Manual1 x Transistor test accessoryNote:We will send you a plug adapter according to your country.
Details Pictures:
