Product Description

Camera Specification??

Item Type: Microscope Camera

Module: HY-5199

Sensor: 16MP CMOS

Optical Format: 1/2.9inch

Pixel Size: 2.85??mx2.85??m

Interface: HDMI (Type A).Small memory card

HDMI Image Resolution: 16MP

Video Resolution: 2K at 30FPS 1080p at 60FPS

HDMI Resolution: 1920 x 1080p 60FPS

HDMI Scale: Support 4: 3,16: 9 screen

Small Memory Card: Up to 64GB (not included)

AWB:?AWB?color correction/automatic/manual

R.G.B value setting independent

Exposure: Automatic/manual. AE value can be set

Cross Line: 8 lines, color, width, position can be set

Scale Line: 2 lines.

Dotted Line: 2 lines, color, width, position can be set

Sharpness Contrast Color Gain: Support

Mono Negative Film: Support

Mirror: Horizontal and vertical mirror

Language: English/Simplified Chinese/French/Spanish/Japanese/German And other languages.

Digital Zoom: Support

Infrared Remote Control: Support

Voltage Input: DC 12V

Power Supply Voltage: Input: AC100-240V

Output: DC12V

Power Consumption: Maximum 0.15W 12V, 0.12A

Lens Interface: C/CS port

Remote Control Battery: 1 x 2302 button battery

150X C-Mount Lens??

Magnification Power by 0.12 - 2X (about 8X -150X on the display)

Visual field :2.4mm-66mm

zoom ratios: 2:1

Size: 100mm(L) * 28mm(DIA)

Weight: 100g

56 LED Microscope Ring Light??

Provides intense and focused shadow-free illumination

144 bright LED

Lighting direction changeable

Variable intensity control

Intense and focused shadow-free illumination

100,000 hours of life

Power input: 100-240V, 50-60HZ, auto switching

Inside diameter of the ring light: 1.0" (27mm)

Overall outside diameter: 1.77" (45mm)

Working Distance: 27mm-120mm

Microscope Bracket

Ring Diameter:42mm(diameter)

Material: Alloy Aluminum, very high quality and easy to carry

Color: black

Material: Aluminium Alloy

Max Diameter of Microscope's Lens Tube: 42mm

Support Height: 310mm

Use: Biology research electronic component precision parts jewelry identification and i dentification circuit board

Package including:

1 x Microscope Camera

1 x 150X C-mount lens

1 x 56 LED light

1 x Power supply

1 x HDMI line

1 x Remote Control

1 x Microscope Bracket

1 x High Temperature Resistant Working Pad
