ANENG CG01 Digital Coating Thickness Gauge | 0-1500um | Backlight LCD | Car Paint & Film Tester
$91.00
$111.98
-19% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Description:ANENG Paint Thickness Gauge is a Backlight LCD Automatic Shutdown Digital Gauge for Automotive Coating Thickness GaugeThe coating thickness gauge integrates the functions of a magnetic thickness gauge and an vortex current thickness gauge, and paint thickness gauge automotive can be used to measure the thickness of coatings on ferrous and non-ferrous metal substrates.
Features:
1. The paint thickness gauge for car's dual-function built-in probe is used to automatically identify iron-based or non-ferrous-based materials, and select the corresponding measurement method for accurate measurement.2. Used for painting, metal processing, sales measurement, automobile paint inspection, used cars, and accident vehicle assessment.3. High measurement accuracy and 0??1500um (0??59.0 mil) wide measurement range.4. 128X64 dot matrix black COG LCD display, the data can be seen clearly even when the backlight is turned off during the day, saving power, and the backlight brightness is adjustable.5. With gravity sensing function, paint gauge thickness gauge can automatically rotate the screen to keep the direction consistent with gravity, making it easy to read the measurement data.6. Paint thickness gauge meter has 6 data group storage functions, which is convenient for statistics and comparison of data and deviations of different parts.7. Paint meter thickness gauge for cars has a 4-point smooth calibration function to make the measurement data more accurate.8. Due to upper and lower limit setting and prompt function, the red and green dual-color LED lights flash, and the screen prompts the limit status.
Specifications:
Item Name: Paint Thickness GaugeType of iron base: magnetic metal iron base (FE) / non-magnetic metal non-ferrous base(NFE)/Automatic recognition.Measuring range: 0 ~ 1500um (0 ~ 59.0 mil).Measurement accuracy: ?? (3% H + 1 um) [?? (3% H + 0.04 mil) ].Measurement method: single measurement / continuous measurementStatistics function: maximum value/minimum value/mean value/varianceNumber of calibration points: 4 calibration points are calculated linearly and smoothly.Data group storage: 6 groups x 100 per group.Minimum convex curvature range: 5mm (197mil)Minimum concave range of curvature: 50mm (1970mil)Minimum measuring area diameter: 20mm (787mil)Minimum substrate thickness: 0.5mm (19.7mil)Display rotation angle: 0??, 90??, 180??, 270??/closeUnit conversion: um/mil.Range of upper and lower limits: 0 ~ 1500um (0 ~ 59.0 mil) freely set/closure.Backlight brightness: 10 levels adjustable/off.Power supply battery: 2X1.5V AAA battery (not included)Replacement battery life: 40 hoursLow battery reminder: lower than 2.4V.Automatic shutdown: Automatic shutdown without operation within 3 minutes.Color box size: 170 X 112 X 70mmProduct weight: 320gColor: Black
Package included:
1 x Coating Thickness Gauge(Not included battery)1 x Storage Bag1 x Lanyard1 x Packing Box1 x User Manual1 x u Disk (1gb)1 x Iron Sheet Test Substrate1 x Aluminum Skin Test Substrate1 x Calibration Standard Test Piece1 x USB Data Cable
