CHIHAI CHF-480WA-5038 DC Gear Motor | 11.1V 37000RPM High Torque High Speed
$45.00
$55.98
-20% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Description:
CHIHAI Motor CHF-480WA-5038 Iron Will-Z Long-Axis DC11.1V 37000rpm High Torque Gear Motor High Speed Long Shaft Airsoft Motor
Specifications:
| Product Name | High Torque Gear Motor |
| Brand | CHIHAI |
| Model | CHF-480WA-5038 |
| Appearance | Shell paint/200?? Thermostable back cover |
| Magnetic Materials | N35 Nd-Fe-b high torque strong output |
| DC11.1V Speed | 37000 rpm |
| No Load Speed | 37000 rpm |
| No Load Current | 3.70A |
| At Stall Torque | 397.75 mN.m |
| At Stall Current | 144.3A |
| Weight | 147g |
| Size | 29.5??25.2mm??88mm (including output shaft and gear) |
| Adaptation Type | No. 2 wave box Airsoft spear JIN MING M4A1-J9 ACR-J10 Wavebox upgrade 480 motor insertion |
| Special Wave Box Type | WARINTEREST JIQU HK416D / KUBLAI BD556 JINGJI SLR / NEW WELL M4 FB WAVE BOX FIGHTING BRO |
| Quantity | 1 Pc ?? Motor |
| At Max Efficiency | ||||
| Speed | Current | Torque | Output Power | Efficiency |
| 31893 rmp | 23.11A | 54.90mN.m | 183.5W | 71.53% |
| At Max Output Power | ||||
| Speed | Current | Torque | Output Power | Efficiency |
| 18500 rmp | 74A | 198.875mN.m | 385.5221W | 46.93% |
Features:
1. Heat resistant, high performance magnets.
2. Highly conductive motor brush.
3. Reinforced motor axle.
4. High torsion magnet, medium and low speed, makes shooting more stable.
5. Low fever type high torsion standard.
Package Included:
| 1 Pc ?? | Motor |
More Details:
