Machifit XL Timing Pulley - 10-40 Teeth | 4-12mm Inner Diameter | CNC Parts
Product Description
Description:
Machifit XL Timing Pulley 10-40 Teeth Synchronous Wheel Inner Diameter 4-12mm For CNC Parts
Specifications:
| Product Name | XL Synchronous Wheel |
Material | Aluminum |
Type of Tooth | XL |
Teeth Pitch | 5.08mm |
Allowable Torque | 30 (N.M) |
Tooth Shape | Trapezoid |
| Suitable For Timing Belt | 10mm Width |
| Quantity | 1 Pc ?? XL Synchronous Wheel |
| Number of Teeth | Tooth Outer Diameter | Inner Diameter | Outside Diameter of Rib | Top Wire Hole | Total Height |
| 10T | 15.66mm | 4mm | 18.5mm | 2*M4 | 20mm |
| 20T | 31.83mm | 35.5mm | 21mm | ||
| 10T | 15.66mm | 5mm | 18.5mm | 20mm | |
| 20T | 31.83mm | 35.5mm | 21mm | ||
| 25T | 39.92mm | 44mm | 2*M5 | 24mm | |
| 30T | 48mm | 52mm | |||
| 10T | 15.66mm | 6mm | 18.5mm | 2*M4 | 20mm |
| 20T | 31.83mm | 35.5mm | 21mm | ||
| 10T | 15.66mm | 8mm | 18.5mm | 20mm | |
| 20T | 31.83mm | 35.5mm | 21mm | ||
| 25T | 39.92mm | 44mm | 2*M5 | 24mm | |
| 30T | 48mm | 52mm | |||
| 40T | 64.17mm | 68mm | |||
| 20T | 31.83mm | 10mm | 35.5mm | 2*M4 | 21mm |
| 25T | 39.92mm | 44mm | 2*M5 | 24mm | |
| 30T | 48mm | 52mm | |||
| 40T | 64.17mm | 68mm | |||
| 20T | 31.83mm | 12mm | 35.5mm | 2*M4 | 21mm |
| 25T | 39.92mm | 44mm | 2*M5 | 24mm | |
| 30T | 48mm | 52mm | |||
| 40T | 64.17mm | 68mm |
Features:
- Accurate transmission, no slippage during work, and constant transmission ratio.
- Smooth transmission, with buffering and vibration reduction capabilities, and low noise.
- High transmission efficiency and obvious energy saving effect.
- Easy maintenance, no need for lubrication, low maintenance cost.
- Large speed ratio range and large power transmission range.
- The teeth are beautiful in shape, precisely mesh with the belt, and have high concentricity.
Package Included:
| 1?? | XL Synchronous Wheel |
More Details:
