ATS MINI ESP32-S3 SI4732 Pocket Radio - DSP Receiver Full Band FM AM SW SSB | 1.9in IPS Screen

Product Description

Specifications:

Main Controller: ESP-32-S3

Working Mode: FM/AM/LSB/USB (note, does not support aviation band)

Frequency Bands: HF/SW/MW/VHF

Frequency Range: LW, MW, SW (150kHz - 30MHz), VHF (64-108MHz)

Display: 1.9-inch IPS screen, 170*320 resolution, adjustable brightness (32-255)

Battery Capacity: 800mAh, approximately 10 hours of runtime

Charging Port: Type-C (non-fast charging)

Audio Jack: 3.5mm three-segment stereo

Antenna Jack: SMA-KE (female center)

Speaker: 1W cavity speaker

Firmware Version: V1.01

Features:

1. Advanced Technology: Equipped with ESP32-S3 main controller and SI4732 DSP chip, supporting FM, AM (MW and SW), LSB, and USB modes. AGC/ATT functionalities enhance reception quality.

2. High-Quality Display: Features a 1.9-inch IPS HD color screen with adjustable brightness, ensuring clear visuals and battery level indication.

3. Long Battery Life: Includes an 800mAh built-in battery providing over 10 hours of continuous use, perfect for extended listening sessions.

4. Superior Audio: Built-in 1W speaker delivers loud and pleasing sound, making your listening experience enjoyable.

5. User-Friendly Operation: All actions are executed with a simple rotary encoder button press and twist, making navigation effortless.

Package Included:

1 x MINI SI4732 Radio Receiver

1 x Telescopic Rod Antenna

1 x Rotatable Loop Antenna
