Siglent SDS1202X-E Oscilloscope - 200 MHz 2 Channel | 1 GSa/s 14 Mpts

Product Description

Features:

1. High-Speed Real-time Sampling: The SDS1202X-E Digital Oscilloscope by Siglent Technologies boasts a real-time sampling rate of up to 1 gsa/use to provide efficient data recording and precision.

2. Vast Record Length: It features a record length up to 14 Mpts, enabling extensive and thorough signal capturing and documentation.

3. Math Co-Processor: The built-in Math co-processor speeds up front panel operations, ensuring brisk processing and display of data.

4. Serial Decoding: The oscilloscope comes with a free standard serial bus triggering and decoding capability that supports IIC, SPI, UART, CAN, and LIN, thus enhancing its versatility.

5. Large, Clear Display: It has a large 7-inch TFT-LCD display with 800 * 480 resolution that delivers clear and detailed images.

Specifications:

Brand: Siglent Technologies

Model: SDS1202X-E

Color: Grey

Channels: 2

Display Size: 7 inch

Real-time sampling rate: 1 gsa/use

Record length:14 Mpts

Waveform capture rate: 100,000 wfm/s (normal mode), 400,000 wfm/s(sequential mode)

Voltage scales: 500 ??V / div to 10 V / div

Package Included:

1 x SDS1202X-E Digital Oscilloscope
