Kaemeasu KM-DM05C Pocket Digital Multimeter | Auto-Ranging AC/DC Voltage Current

Product Description

Features:

Introducing the KM-DM05C, a pocket-sized multifunctional digital multimeter designed to meet all your testing needs. This compact, high-precision electrical tool is perfect for both electricians and DIY enthusiasts alike.

High Precision & Wide Range of Measurements: It can accurately measure AC/DC voltage, AC/DC current, resistance, frequency, capacitance, perform continuity tests and diode testing.

Safety First: To ensure your safety during usage, the meter is equipped with surge protection, effectively guarding against any electrical discharges.

Compact & Easy-to-use: Its sleek design and simple operations make it an ideal tool for both professionals and amateurs.

Automatic Measuring: This 3 5/6 automatic measuring range instrument adjusts itself to your testing requirements, simplifying your work process.

LCD Display: Features an easy-to-read LCD display with automatic polarity indication.

Specifications:

Brand: Kaemeasu

Model: KM-DM05C

DC Voltage: 60mV/600mV/6V/60V/600V

AC Voltage: 60mV/600mV/6V/60V/600V

DC Current: 600uA/6000uA/60mA/600mA/6A/10A

AC Current: 600uA/6000uA/60mA/600mA/6A/10A

Resistance: 600??/6K??/60K??/600K??/6M??/60M??

Capacitance: 10nF/100nF/1nF/10uF/100uF/1mF/10mF/100mF

Frequency: 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz

Duty Cycle: 0.1%-99%

Additional Functionality:

True RMS measurement: Yes

NCV Measurement: Yes

Auto/Manual: Yes

Diode Test: Yes

Continuity Buzzer: Yes

LCD Backlight: Yes

Low Voltage Display: Yes

Data Hold: Yes

Flashlight: Yes

Auto Power Off: Yes

General Characteristics:

Display: Liquid Crystal Display (LCD)

Maximum display: 5999 (3 5/6) bits Automatic polarity display

Working environment: (0??40)??, relative humidity??80%

Power supply: 2 * 1.5V AAA battery (Not included)

Volume (size): 152??73??48mm

Weight: 227g

Package Includes:

1 x Digital multimeter

1 x Test leads

1 x English manual

1 x Color box

Please note: The product is sent without a battery.
