BSIDE ADMS6 Digital Multimeter - 6000 Counts True RMS Autoranging | V-alert & Live Wire Test

BSIDE ADMS6 Digital Multimeter - 6000 Counts True RMS Autoranging | V-alert & Live Wire Test - Image 2

BSIDE ADMS6 Digital Multimeter - 6000 Counts True RMS Autoranging | V-alert & Live Wire Test - Image 3

BSIDE ADMS6 Digital Multimeter - 6000 Counts True RMS Autoranging | V-alert & Live Wire Test

Name: BSIDE ADMS6 Digital Multimeter - 6000 Counts True RMS Autoranging | V-alert & Live Wire Test
Brand: VQTool
SKU: PR-488E92
Price: 27.00 USD
Availability: InStock

SKU: PR-488E92

In Stock (999 available)

$27.00 $33.58 -20% OFF

Quantity:

Add to Cart Wishlist

Global Shipping

Easy Returns

Secure Payment

Product Description

>>Please Click Here to Download the ADMS6 manual(English/German/French/Japanese/Spanish/Italian)<<
Features:
Display: 6000 counts
DC/AC Current Measurement DC/AC Voltage Measurement Resistance/Continuity/Frequency Measurement Automatic measuring range Full measuring range overload protection True RMS Auto power off Backlight Low Battery indication Date hold V-alert Test(dangerous voltage alarm) Live wire and null wire test
Specifications:
Max voltage allowed at the measuring end.:600V DC or 600AC(RMS).
Work height: max 2000m Display:LCD. Max display value: 5999 digits. Polarity indication:Self-indicating, ??-?? means Negative polarity. Over-range display:??0L?? or ??-0L??. Sampling time:The meter figures show about 0.4 seconds
Unit display:Function and battery unit display. Automatic Power off time: 15 minutes
Operational power:1.5Vx2 AAA battery.(not included) Battery low voltage indication: LCD display symbol. Temperature coefficient:Less than 0.1 x Accuracy / ?? Operational temperature and humidity : 0~40 ??/32~104?H 45%-80%RH
Storage temperature and humidity:-10~60 ??/-4~140?H 45%-80%RH
Boundary dimension:139??83??36mm Weight: ~160g
1. Voltage DC

Range	Resolution	Accuracy
600V	0.1V	??(0.8%+3counts)

Sensitivity: min 0.5V DC voltage Input impedance: 1M??
Max input voltage:600V DC&AC (RMS)
2. Voltage AC

Range	Resolution	Accuracy
600V	0.1V	??(1.2%+5counts)

Sensitivity: min 0.5V DC voltage Input impedance: 1M??
Max input voltage:600V DC&AC (RMS)
Frequency range: 50Hz~60Hz, true RMS response.
3. Resistance

Range	Resolution	Accuracy
6000??	1??	??(1.2% +3counts)

Overload protection:600V DC or AC(RMS)

4. Current DC

Range	Resolution	Accuracy
200mA	0.1mA	??(1.2%+3 counts)

Sensitivity: min 0.5mA DC current.
Overload protection:600V/200mA self-recovery fuse. Frequency range: 50Hz~60Hz.
5. Current AC

Range	Resolution	Accuracy
200mA	0.1mA	??(1.5%+5counts)

Sensitivity: min 1mA AC current.
Overload protection: 600V/200mA self-recovery fuse. Frequency range: 50Hz~60Hz.
6. Frequency

Range	Resolution	Accuracy
1000Hz	1Hz	??(1.0%+5counts)

Frequency range: 40Hz~1000Hz.
7. Measure Continuity

Function	Accuracy
buzzer	If the resistance is <30??, the continuity beeper sounds.

Overload protection:6000V DC or AC(RMS)

8. V~Alert

Range	Explanation
Low file	Show -EF-, green V~Alert light continue light on, the beep sounds
Hgh file	Show -EF-, red NCV light continue light on, the buzzer sounds an alarm at a higher frequency
