ANENG Q10 Digital Multimeter - True RMS 9999 Count | NCV & Transistor Tester
$52.00
$63.98
-19% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Features:
ANENG Q10 is an automatic range digital multimeter with 9999 words with a true effective value. The instrument is full-key operation with triple display.
Measure AC voltage and DC voltage
Measure AC and DC current
Measuring resistance/temperature
Test continuity and diode
Measuring capacitance/NCV
Measuring frequency and duty cycle
Anti-interference AC voltage detection
Specification:
| Brand | ANENG | Model | Q10 |
| Display (LCD) | 9999 | Range | automatic / manual |
| Material | ABS+TPE | Sampling rate | 3 times/sec |
| True RMS | yes | Data retention | yes |
| Screen backlight | yes | Low battery warning | yes |
| Automatic shut-down | yes | type of battery | 3 * 1.5V AA battery (not included) |
| Features | Range | Precision | AC frequency response |
| DC Current | 9.999A/999.9mA | ??(1.0%+3) | - |
| DC Current | 99.99mA/9.999mA/99.99??A/999.9??A | ??(0.8%+3) | - |
| AC current | 9.999A/999.9mA | ??(1.2%+3) | 40Hz~1kHz |
| AC current | 99.99mA/9.999mA/99.99??A/999.9??A | ??(1.0%+3) | 40Hz~1kHz |
| DC voltage | 999.9mV/9.999V/99.99V/999.9V/9.999mV/99.99mV/999.9mV | ??(0.5%+3) | - |
| AC voltage | 999.9mV/9.999V/99.99V/750.0V/9.999mV/99.99mV/999.9mV | ??(1.0%+3) | 40Hz~1kHz |
| Resistance | 99.99?? | ??(1.0%+3) | - |
| Resistance | 999.9??/9.999k??/99.99k??/999.9k?? | ??(0.5%+3) | - |
| Resistance | 9.999M?? | ??(1.5%+3) | - |
| Resistance | 99.99M?? | ??(3.0%+5) | - |
| Capacitance | 9.999nF | ??(5.0%+20) | - |
| Capacitance | 99.99nF/999.9nF/9.999??F/99.99??F/999.9??F | ??(2.0%+5) | - |
| Capacitance | 9.999mF | ??(5.0%+5) | - |
| Frequency | 99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/5.000MHz | ??(0.1%+2) | - |
| Temperature | (-20~1000)?? / (-4~1832)?H | ??(2.5%+5) | - |
| Duty cycle | 1%~99% | diode | yes |
| On and off | yes | NCV | yes |
| working environment | temperature | 0~40?? | |
| humidity | ??75% |
Package Includes:
1 * ANENG Q10 Digital Multimeter (Battery not included)
2 * Test lead wire
1 * Thermocouple
1 * Manual
Details Pictures:
