Machifit JGB370 DC12V Worm Gear Motor - Hollow Shaft Micro DC Gear Motor
Product Description
Description:
MACHIFIT DC12V JGB370 Worm Gear Motor Hollow Shaft Micro DC Gear Motor
Specifications:
| Product Name | DC Worm Gear Motor |
| Material | Metal |
| Rated Voltage | DC 12V |
| No-load Speed | 6/10/18/23/30/40/90/150 RPM |
| Shaft Shape | Hollow shaft |
| Quantity | 1 Pcs |
| DC12V Motor Parameters | ||||||||
| Reduction ratio (change ratio) | 40 | 65 | 150 | 200 | 260 | 340 | 600 | 1000 |
| No-load current (MA) | ??60 | |||||||
| No-load speed (rpm) | 150 | 90 | 40 | 30 | 23 | 18 | 10 | 6 |
| Rated torque (Kg.cm) | 1.2 | 2 | 4.5 | 6 | 8 | 12 | 17 | 25 |
| Rated speed (rpm) | 100 | 70 | 30 | 22 | 17 | 13 | 7 | 4 |
| Rated current (A) | ??0.5 | |||||||
| Maximum torque | 2.5 | 4 | 9 | 12.5 | 16 | 21 | 35 | 35 |
| Stop current (A) | 1.3 | |||||||
Features:
- This type is miniature worm gear DC motor, which can change shaft rotation direction while the wiring positive and negative be changed.
- It is also have addition two characteristics: first, With self-locking, the output shaft can not rotation when switch off, that is self-locking. Second, Output shaft and motor shaft are come to be a rectangle.
- It is widely used in various of ocns that require special install size.
- Using high-precision metal gears, low noise, zinc alloy die-casting alloy pressure shell, stainless steel hardened.
- Ball precision gears have better performance than ordinary metal gears. - They are resistant to blocking and do not hit gears.
- Suitable for electronic locks, range hoods, display stands, robots, smart devices and barbecue machines.
Package Included:
| 1?? | DC Worm Gear Motor |
