Chihai CHP-6GP-C0609 6mm Planetary Gear Motor - Hollow Cup - Tiny Size

Product Description

Descriptions: Chihai CHP-6GP-C0609 tiny hollow cup planetary reduction gear motor diameter 6mm Specifications: Brand: Chihai Motor Model: CHP-6GP-C0609 tiny hollow cup reduction gear motor Reduction box diameter: 6mm Total height: 16.5mm(without shaft) Shaft length: 2.8mm
Shaft diameter: 1.95mm
Weight: About 1.2g
Application: Smart fingerprint lock, luggage lock, robot, financial machinery, armarium, massage, high equipment etc.

Model	Ratio	Voltage		No load		At rated load			Stall
		Length (mm)	Nominal	Speed	Current	Speed	Current	Torque	Current	Torque
				r/min	mA	r/min	A	g.cm	A	g.cm
CHP-6GP-L610-26	1:26	7.05	3.0	1200	??60	720	??0.15	28.0	??0.25	??70
CHP-6GP-L610-136	1:136	9.40		240		145		140.0		??300

Features: - Pure copper wire winding, no iron core, uniquely designed high coil; - Neodymium iron boron magnet, low temperature rise, which guarantees the stability of the motor; - Planetary reducer, high transmission efficiency, low noise, and can carry large torque; - Excellent volumetric power ratio, light weight, smooth operation and response. Package Included: 1 x Reduction Motor More Details:
