HT-19 Handheld Infrared Thermal Imager Camera - 320x240 IR Detector with 3.2 Display & Storage
$792.00
$974.38
-19% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Descriptions: Infrared thermal imager that can blend the visible and infrared image This infrared imaging device is professional, precision and efficient. For car engine overhaul, transformer room line maintenance, air conditioner repair, etc. Our infrared thermal imager can turn thermal image into visional image, quickly find out the problem area. Features: - 3.2'' full color screen, allows for detailed showing of infrared generated images; - 320x240 resolution and 0.3 million pixel visible image resolution, high definition of images; - -20~300deg/-4deg~572deg temperature measurement range, 2.5deg accuracy for better operation; - 5 kinds of palette for choice: rainbow, iron red, cold color, black & white and white & black; - Automatic setting: 5 mintues/20 minutes/ not power off automatically; - Built-in 4GB SD card for storage, the pics can be also transferred to television, computer or other devices for checking; - Wide application at medical, fire-fighting, archaeology, traffic, farming, electronic manufacture and other fields; - Seperate button for specific function, which is quite easy for you to turn it on or off, delete or check pictures; - Mini and portable for 90times105times223mm size and 289g weight, attached pouch allows for more convenient carrying; - Ergonomic handle, which can be used and held comfortably.Specifications:
| Model | HT-19 |
| Display: | 3.2'' full-color screen |
| Infrared image Resolution: | 320*240 |
| Total Pixel: | 76,800 pixels |
| Visible image resolution: | 0.3 mega pixels. |
| Thermal sensitivity: | 0.07?? |
| Temperature range: | -20?? to 300??(-4?H to 572?H) |
| Measuring Accuracy: | ??2% or ??2??(??4?H) |
| FOV/Shortest Focal Length: | 27???35??/0.5m |
| Thermal Sensitivity: | 0.5?? |
| Wavelength Range: | 8-14??m |
| Emissivity: | 0.1-10.0 Adjustable |
| Image Frequency: | 8HZ |
| Focus Mode: | Fixed |
| Vision Option: | full infrared and full vision Visible image with 25% step length |
| Image Storage: | SD card(4G) |
| File Format: | JPG |
| Battery Supply: | built-in chargeable 18650 |
| USB: | Micro USB2.0 |
| Auto Power off Time: | 5 mintues/20 minutes/ not power off automatically |
| Authentication: | CE, RoHS |
| Operating Temperature: | -5?? to 40?? (23?H to 104?H) |
| Storage Temperature: | -20?? to 50?? (-4?H to 122?H) |
| Relative Humidity: | 10%RH to 80%RH |
| Item Size: | 223??105??90mm |
| Item Weight: | 289g |
Package includes: 1 x Infrared Thermal Imager 1 x cable 1 x user manual 1 x carry pouch 1 x carry pouch strap 1 x cardboard package box
Details Pictures:
