NanoVNA RF Demo Kit - Tester Board with Filter & Attenuator for NanoVNA-F
$30.00
$36.78
-18% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Description:- PCB board in size of 10 x 10cm - Vector network analyzer learner tool - RLC series and parallel circuit 1 - RLC series and parallel circuit 2 - 33 ohm resistance, SWR=1.5 - 75 ohm resistance, SWR=1.5 - BSF ceramic notch filter, center frequency 6.5MHz - BPF ceramic filter, centre frequency 10.7MHz - RC series circuit - LC series circuit - Capacitor - Inductance - Homemade low-pass filter, 3dB bandwidth 400MHz - Homemade high-pass filter, 3dB bandwidth 500MHz - Short-circuit calibration circuit - Open-circuit calibration circuit - 50 ohm load calibration circuit - Straight-through - 10dB attenuation circuit - 3dB attenuation circuit - Each set of functional circuits Applications:
- Can be used with NanoVNA-F to measure 6.5M ceramic notch filter - Can be used wtih NanoVNA-F to measure homemade low-pass-filter, 3dB bandwidth about 400MHz Package Included:
1 x PCB RF Tester Board 2 x 20cm Adapter Cables
