HAYEAR 4K Digital Microscope Camera - 60FPS for Phone Repair & PCB Soldering

Product Description

Feature:
1. Widely used in the fields of microelectronics, molds, jewelry, printing, mobile phone repair schools, etc.
2. Especially suitable for observing the surface microstructure of large objects.
3. Using high quality materials, strong , has a long service life.
4. HD camera with 8 megapixel CMOS sensor 1/1.2 inch, withHDMI USB port.
5. Strict quality control and quality assurance, high safety factor, can be used with peace of mind.
Specification:
Item Type: Microscope Camera
Model: HY-6800
Sensor: For CMOS IMX 585 Sensor
Optical Format: 1/1.2inch
Pixel Size: 2.9??mx2.9??m
InterfaceHDMI (Type A).USB (Type B Type-C 3.0 ) .USB (Type C USB Disk storage).
HDMIImage Resolution: 8MP
HDMIVideo Resolution: 4K:3840x2160P 60FPS 2K:1920x1080P at 60FPS
HDMIScale: Support 4: 3,16: 9 screen
USB3.0 (Type-C 3.0): 4K:3840x2160P 30FPS 2K:1920 x 1080 at 60FPS
USB Disk storage: Up to 512GB (not included)
AWB:AWB color correction/automatic/manual
R.G.B value setting independent
Exposure: Automatic/manual. AE value can be set
Cross Line: 8 lines, color, width, position can be set
Scale Line: 2 lines.
Dotted Line: 2 lines, color, width, position can be set
Sharpness Contrast Color Gain: Support
Mono Negative Film: Support
Mirror: Horizontal and vertical mirror
Language: English/Simplified Chinese
Digital Zoom: Support
Working Voltage:DC 12V/ 1000mA
Lens Interface: C/CS port
Camera size 62x43x62MM??LxWxH??
Package size 210x140x80MM??LxWxH??
Package Included:
1 x Microscope Camera
1 x Power Supply
1 x Type-C Cable
1 x HDMICable
1 x Software Disk
1 x Mouse
