Product Description
Features:1. Find and check the line from the Poe switch.2. STP shielded cable is provided, which can be used to connect various network cables and BNC cables.3. Provide LED lights. It is convenient to find lines in dark or unlit places.4. A wide range of applications, such as electric power, line maintenance, network line engineering, monitoring installation and other industries.5. Support online search. The 8p network cable is inserted into the 8p/6p common hole for live signal test. But the alligator clip must be grounded at the same time, otherwise the test cannot be performed. 6p phone line search, insert 6p special hole or use 6p alligator clip to test.6. Support line order fault test. Can quickly determine the line open circuit, path, short circuit, intersection, etc. The audio transmitter directly presses the test button twice (low speed), the receiver directly displays the line order light number and compares the test results.7. Unilateral test the on-off status of the network cable near the signal. It can be judged whether the line is on or off according to whether all the 1-8 lights in the line order are on, but the short circuit and splitting of the line cannot be judged from this.8. Coaxial cable and wire connection test. Connect the alligator clip line, connect one end of the line to the black alligator clip, and the other end to the red alligator clip, press the ?? key, and judge the line on or off and short-circuit on the indicator light according to the open circuit.9. Support mobile phone polarity test. Connect the alligator clip wires, respectively clamp the phone wires under test, press the pol key, and judge the positive and negative polarity of the circuit by the color of the Pol+/- light.
Specifications:
- Frequency range: 130KHZ
- Model: MT-7029-C
- Fault test distance: 300M
- Working current: <70MA
- Audio test distance: ?? 3km
- Battery 1: DC 9V without battery
- Audio transmitter test socket: RJ45 (8pin)/RJ11 (6pin) wire pair test
- RJ45 scanning socket: Provide RJ45 (8pin) audio search
- RJ11 scanning socket: Provide RJ11 (6p / 6C / 4C / 2C) audio search short circuit: 1 LED display
- Output signal voltage: 8vp-p
- Line order/fault indication: 8 LEDs, fast/slow speed test
- Audio transmitter voltage protection: DC 48V
- Automatic shutdown: about 1 hour
- Appearance size 1: 138*80*35mm
- Receiver audio frequency: 130KHz
- Receiver working current: 115mA
- Receiver test connection: RJ45 (8pin)/RJ11 (6pin) shared socket Receiver function selection: 4-segment slide switch
- Headphone stand: 1
- Signal strength indication: 1 two-color LED and buzzer
- Non-contact power test (NCV) indication: 1 LED (AC 90~1000V)
- Work lighting: 1 LED
- Battery 2: DC 9.0V NO battery
- Appearance size 2: 203*50*32mm
Package Included:
1 X audio transmitter1 X receiver
Notes:
1. It is strictly forbidden to connect a live wire with voltage (such as a network cable Poe power supply module) at the receiving end.2. Do not connect the 48V DC port to the transmitter port for measurement.
