HT-1200 Ultrasonic Thickness Gauge | 1.2-225mm Range | 0.1mm Resolution | 4-Digit LCD
$142.00
$174.38
-19% OFF
Global Shipping
Easy Returns
Secure Payment
Product Description
Features:Display mode: Four-digit LCD display.
Working frequency of the probe: 5MH
Range: 1.5~
Resolution ratio: 0.1mm
Measurement accuracy: ??(1%H+0.1)mm, H is the object thickness.
Lower measurement limit of pipes: ??20??3mm
Sound speed adjustment scope: 1000
Measuring sound speed with known thickness: Measurement scope:1000~9999m/s;
when thickness of measured objects is ??20mm, the precision of sound speed measurement is ??1mm/H*100%;
when the object thickness is > 20mm, precision of sound speed measurement is??5%.
Power supply: 3 x 1.5V AA alkaline batteries(not included)
Working temperature: 0~40??
Relative humidity: < 90%RH
Storage temperature: -10~50??
Workpiece temperature: < 60??
Working current: < 100mA
Product size:152mm??75mm??32mm
Package includes:
1 x Ultrasonic Thickness Meter
1 x Probe
1 x User Manual
1 x Box
