Chihai CHF-GM12-N20VA Gear Motor - 12V DC | 50:1 Reduction Ratio

Product Description

Descriptions: Chihai CHF-GM12-N20VA screw reduction gear motor reduction ratio 1:50 Specifications: Brand: Chihai Motor
Voltage: DC 6.0V/12.0V
Size: 12 x 10mm Length: 26mm Shaft Diameter: M4 x 0.5 screw thread Output Shaft Long: About 55mm Weight: About 12g

Reduction ratio	1:50
Voltage (V)	6.0	12.0
Model	A05
No-load current (mA)	??30	??40
No-load speed (rpm)	155	300
Rated torque (Kg.cm)	0.10	0.20
Rated torque (N.m)	0.01	0.02
Rated speed (rpm)	60	165
Rated current (A)	??0.08	??0.1
Locked-rotor current (A)	??0.2	??0.3
Locked-rotor torque (Kg.cm)	0.20	0.40

Features:
- Stainless steel support shaft ensures stable linear drive; - Large torque, adjustable, positive and negative; - Low energy consumption and low noise; - Powerful, durable and long life; - Special landing gear geared motors for mini fixed-wing aircraft; - For wireless control models and some small appliances, high-demand geared motors, beauty equipment, instrumentation, electric slides, electric pan/tilt, etc. Package Included: 1 x Reduction Gear Motor More Details:
