Chihai CHF-FK180SH DC 6V 7800RPM High Speed Motor | Micro DC 180 with Encoder

Product Description

Description:

Chihai Motor CHF-FK180SH DC 6V 7800RPM High Speed Motor Micro DC 180 Motor High Speed With Encoder Specification:

Brand	Chihai motor
Product Type	CHF-FK180SH-12160 Mini Dc Motor High speed encoder motor for Toy DIY
Shaft diameter	2mm
Shaft Length	8.5mm
Voltage	DC 6V
No load speed	7800rpm
No load current	0.10A
At stall torque	10.55mN.m
At stall current	??2.1A
Weight	About 40g
Wiring specification	PH2.0-6PIN terminal connector
Encoder Specifications	AB dual phase encoder 11 line basic signal voltage 3.3 V or 5.0 V
Applications	Blood pressure pump, camcorder, electric shaver, toy, garbage disposal machine, stage light stand, coffee machine, automatic actuator, boiler valve, washing machine

Feature: - AB phase dual hall encoding board withbuilt-in pull-up resistence. - Metal gear reduction mechanism: high strength, stable transmission, high efficiency and high torque. - Frequent blocking or frequent start-up and upset are not recommended in the process of use, which will significantly reduce the service life. Package Included: 1 x Gear Motor
