CHIHAI 24V 75RPM High Torque Turbo Worm Gear Motor | with Bracket & Coupler

Product Description

Description:
CHIHAI CHW-GW4632-370 DC 24V 75rpm 1:158 Reversible high torque turbo, worm reducer gear motor with bracket and nut.
Specification:

Type	CHW-GW4632-370
Shaft diameter	M6
Shaft length	55mm
Voltage	DC 1.5V-2.4V
Working voltage	24V
Power max	12W
Reduction ratio	1:158
No-load current	??150A
No load speed	75RPM
Rated torque	6.0kg.cm
Rated speed	53RPM
Rated current	??0.7A
Locked-rotor torque max	??35.0kg.cm
Plug the plug to turn the current	??2.0A
Application	Office equipment, robot, camera rocker arm, home appliances.

Features:
1. Worm gear reduction drive, power off self - locking force.
2. Pure copper winding: the rotor is made of pure copper, with small resistance and strong conductivity, which increases the torque of the motor.
3. Thread tapping axis: M6 national standard thread tapping axis, the length can be customized.
4. All metal gear, positive and reverse turn, adjustable speed.
5. Low consumption, energy saving, high torque, low noise, durable, stable power.
Package Included:
1 X Worm reducer gear motor
