Mitutoyo Stainless Steel Inside Micrometer | Metric Vernier Caliper Gauge Tool

Product Description

Description:

Stainless Steel Inside Micrometer Screw Gauge Metric Measuring Vernier Caliper Gauge Measuring Tool

Specifications:

Features:

- High quality alloy measuring heads can be used for various internal size measurement, fine workmanship and no burr.

- Clear laser marking line for convenient reading.

- The main micrometer body is ade of stainless steel with chrome plated surface, wear-resisting and durable.

- Designed with locking device, precise machinery structure make it more intuitive and convenient to read.

- Built-in ratchet shop device ensures accurate repetitive readings.

Zeroing:

- Clean the surface of measuring anvil heads with a soft cloth, then rotate measuring device to make two measuring surface contact. If two zero lines of differential sleeve and fixed barrels do not alignment, use the following two methods to adjust.

- Method 1??If the error is less than 0.02mm (0.001"), use ratchet stop to lock screw tightly, then use wrench to pull fixed barrels till two zero lines alignment.

- Method 2??If the error is greater than 0.02mm (0.001").

Step1, use ratchet stop to lock screw tightly, then use wrench to loosen the ratchet stop and remove differential sleeve.

Step2, re-align zero lines of fixed barrels and differential sleeve, then put ratchet stop back on. If necessary, adjust it again using method 1.

Note:

There is no need to calibrate micrometer during common use. Micrometer only need calibration when it is severely worn.
